Crowcon Smart 3G-C2

The Crowcon Smart 3G-C2 is designed for continuous protection in facilities where gas hazards and process uptime are both critical. SIL2-certified functional safety, supported by high-integrity software and redundant safety concepts, provides a strong basis for use within safety instrumented systems. Continuous self-diagnostics monitor detector status and signal faults early, helping operators maintain confidence in the gas detection layer of protection and supporting compliance with internal and external safety requirements.

The detector monitors toxic, flammable, VOC and refrigerant gases, as well as oxygen deficiency and enrichment when fitted with an oxygen sensor. This breadth of coverage allows a common detector platform to be deployed across diverse applications, simplifying engineering design, operating procedures and training.

The Smart 3G-C2 supports more than 50 gases using catalytic bead, infrared, electrochemical and PID sensor technologies. Catalytic and infrared sensors cover flammable gases and vapours, while electrochemical cells address an extensive range of toxic gases and oxygen. Dedicated infrared options provide monitoring for carbon dioxide, refrigerants, F-gases and sulphur hexafluoride, supporting applications from process safety to electrical switchgear monitoring.

PID sensors extend detection to volatile organic compounds over multiple measurement ranges, making the detector suitable for leak detection, process monitoring and exposure control tasks. The availability of different sensor types within a single family enables engineers to standardise on one detector platform while selecting the optimum sensing principle for each hazard, reducing spare parts inventory and simplifying lifecycle management.

The Crowcon Smart 3G-C2 is suitable for fixed installation in Zone 1 hazardous areas, including locations where explosive gas atmospheres are expected frequently or continuously. ATEX Category 2 approvals and the option to upgrade from gas-only to combined gas-and-dust protection via dedicated adapters support deployment in mixed-risk areas. Additional approvals such as EMC and IECEx enable use in projects with international regulatory requirements.

An IP65-rated aluminium pressure die-cast housing with chemically resistant epoxy coating provides strong mechanical protection and resistance to challenging atmospheres. Wide operating temperature capability and high humidity tolerance support reliable performance in both indoor plant areas and exposed outdoor locations. Intrinsically safe variants for selected toxic gases further enhance suitability for high-risk zones.

The detector is engineered for fast response, helping provide early warning of hazardous gas accumulations so that evacuation, process adjustment or shutdown measures can be initiated in time. Zero tracker/zero follower functionality acts to counter sensor drift, supporting stable readings between service intervals and helping maintain measurement accuracy over the detector’s operating life.

This combination of rapid response and long-term stability supports both safety and operational objectives, reducing the likelihood of nuisance alarms while maintaining sensitivity to genuine leaks and process deviations.

The Smart 3G-C2 is designed for straightforward integration into new builds and retrofit projects. A standard three-wire 4–20 mA analogue output allows direct connection to PLCs, DCS and dedicated gas control panels, including Sensitron systems and third-party platforms. An optional RS485 interface with Modbus communication enables multi-drop architectures, centralised supervision and easier data collection across larger installations.

Optional 1- or 3-relay output boards provide local alarm, interlock and shutdown capability at the detector, shortening response paths and reducing reliance on separate interface hardware. Three 3/4″ NPT cable entries give flexibility for different wiring practices and conduit systems, simplifying installation layout in crowded or constrained plant areas.

The Crowcon Smart 3G-C2 range offers two main housing formats tailored to different sensor configurations, balancing mechanical robustness with comparatively low weight to ease handling and mounting. Remote sensor head kits, available in different cable lengths, allow the sensing element to be located in confined or hard-to-access points while keeping the detector electronics in a safer, more accessible position. This arrangement supports safer maintenance and can reduce the time required for routine service work.

Field calibration is carried out via compatible handheld keypads, enabling zero and span adjustment without removing the detector or opening the enclosure, which helps minimise disruption and permitting requirements in hazardous areas. Data logging functions, accessed through the keypad or configuration software, provide traceable records for audits, trend analysis and optimisation of alarm settings.

Calibration and configuration software allows adjustment of alarm thresholds, measurement ranges and 4–20 mA mapping so that each detector can be aligned with site-specific risk assessments and control philosophies. Simple sensor replacement and the availability of spare sensor heads and complete detectors support a planned maintenance strategy and help minimise downtime.

The Smart 3G-C2 forms part of the Sensitron SMART 3G series, allowing consistent integration across wider fixed gas detection systems. Support for flammable gas monitoring at LEL levels alongside ppm-level toxic, VOC and refrigerant detection within the same product family enables standardisation across diverse plant areas using common hardware, tools and procedures.

The detector is suited to applications in sectors such as oil and gas, petrochemical, chemical processing, power generation, pharmaceuticals and refining. As part of a global gas detection portfolio within the Halma group, it benefits from long-term product and service support. Manuals, datasheets, certificates and functional safety documentation are readily available to assist with specification, tendering and compliance, while technical support and training provided through distributors and resellers help ensure correct selection, commissioning and operation over the system’s life.
